Description
SpecificationsCertifications
| ADA Compliant | ADA Height and Side Reach Compliant |
| UL | Yes |
| Prop 65 | CALIFORNIA RESIDENTS ONLY – WARNING: Cancer and Reproductive Harm – |
Details
| Cooktop Configuration | All Burners |
| Installs Over Built-In Oven | Yes |
| LP Convertible | Yes – Kit Included |
| Power Outage Compatible | Yes |
| Cooktop Surface Color | Stainless |
| Digital Display | No |
Element/Burner Details
| Center Element Burner Power | 18,000 BTU |
| Center Element Burner Type | Power |
| Cooktop Element Style | Sealed Burner |
| Left Front Element-Burner Power | 12000 BTU |
| Left Front Element-Burner Type | Standard |
| Left Rear Element-Burner Power | 5000 BTU |
| Left Rear Element-Burner Type | Simmer |
| Number of Cooking Element-Burners | 5 |
| Power Boost | No |
| Right Front Element-Burner Power | 9100 BTU |
| Right Front Element-Burner Type | Standard |
| Right Rear Element-Burner Power | 9100 BTU |
| Right Rear Element-Burner Type | Standard |
| Automatic Pan Detection | No |
| Automatic Pan Size Adjustment | No |
| Number of Grates | 3 |
Exterior Details
| Knob Color | Stainless Steel |
| Knob Type | Plastic |
Grate Details
| Grate Details | Cast Iron Grates , Continuous with Hinge , Dishwasher Safe , Matte Finish |
| Number of Grates | 3 |
Dimensions
| Cutout Depth | 20 in |
| Cutout Depth Max | 20 in |
| Cutout Depth Min | 19 in |
| Cutout Width | 35-1/4 in |
| Cutout Width Max | 35-1/4 in |
| Depth | 21 in |
| Gross Weight | 73-9/25 lbs |
| Height | 5-9/16 in |
| Net Weight | 66-7/10 lbs |
| Width | 36 in |
Controls
| Control Location | Front |
| Control Type | Knobs |
Ventilation Details
| Downdraft Vent | No |
| Ventilation Type | N/A |
| Venting | N/A |
Smart Compatibility
| Works With | No |
Dimensions
| Gross Weight | 73-9/25 lbs |
Cooktop Details
| Cooktop Surface Color | Stainless |
| Digital Display | No |
| Griddle Included | N/A |
| Heating Element On Indicator Light | No |
| Hot Surface Indicator Light | No |
| Ignition Type | Direct Spark Ignition |
| Combination Match with Oven | WOES3027L , WOES3030L , WOES5027L , WOES5030L , WOES5930L , WOES7027P , WOES7030P , WOS31ES0 , WOS31ES7 , WOS51EC0 , WOS51EC0A , WOS51EC7 , WOS51EC7A , WOS52EM4 , WOS52ES4M , WOS72EC0 , WOS72EC7 , WOS92EC7 |
| Installs Over Built-In Oven | Yes |
Electrical Requirements
| Power Cord Included | Yes |
Documents
Dimension GuideDownload (PDF 1010.0KB)
Owner’s ManualDownload (PDF 1.4MB)
WarrantyDownload (PDF 344.0KB)
Parts ListDownload (PDF 944.0KB)
Quick Reference SheetDownload (PDF 1.4MB)
Control GuideDownload (PDF 3.2MB)
