Description
FeaturesPower Simmer Dual Stack BurnerThe Power simmer dual stacked burner gives you precise control over your cooktop, allowing you to boil water rapidly or gently hold low temperatures to simmer sauces – all with one Protective FinishThe DuraGuard protective finish keeps the cooktop surface lookin’ like new and cleans with ease year after Burner with Melt CapThe simmer burner allows for adjustable heat control from 800 to 5,000 BTUs. The addition of a melt cap on the burner diffuses the flame for low-heat melting or warming without the need for constant Continuous Cast Iron GratesDishwasher safe DuraClean cast-iron grates let pots and pans smoothly slide around the cooktop for fewer spills and easier transitions from burner to BurnerThe Power Burner allows for a slow, even sauté and the intense heat for a seared, juicy Surface BurnersThese burners are sealed, creating a smooth surface for even heating, easy cleanup and extended grate life. Plus, it helps to keep food from falling below the , Engineered, and Assembled in the USAFrom Tennessee to you, these cooktops are designed, engineered and assembled in the U.S.A.5 BurnersWith an extra burner you have the flexibility to prepare all your meals without juggling pots and pans.10 Year Limited Parts WarrantyWith a 10-year limited parts warranty on the cooktop burners and cast-iron metal grates, we built these cooktops tough enough to keep cookin’ for
| ADA Compliant | ADA Height and Side Reach Compliant |
| UL | Yes |
| Prop 65 | CALIFORNIA RESIDENTS ONLY – WARNING: Cancer and Reproductive Harm – |
Details
| Fuel Type | Gas |
| Installs Over Built-In Oven | Yes |
| LP Convertible | Yes – Kit Included |
| Power Outage Compatible | Yes |
| Cooktop Type | Standard |
| Cooktop Surface Color | Color Coordinated |
| Digital Display | No |
Element/Burner Details
| Center Rear Element-Burner Type | Dual |
| Center Rear Element-Burner Power | 18,000 BTU |
| Cooktop Element Style | Sealed Burner |
| Cooktop Type | Standard |
| Left Front Element-Burner Power | 9,100 BTU |
| Left Front Element-Burner Type | Sealed Burner |
| Left Rear Element-Burner Power | 9,100 BTU |
| Left Rear Element-Burner Type | Sealed Burner |
| Number of Cooking Element-Burners | 5 |
| Power Boost | No |
| Right Front Element-Burner Power | 12,000 BTU |
| Right Front Element-Burner Type | Sealed Burner |
| Right Rear Element-Burner Power | 5,000 BTU |
| Right Rear Element-Burner Type | Simmer |
| Automatic Pan Detection | No |
| Number of Grates | 3 |
Exterior Details
| Knob Color | Stainless Steel |
| Knob Type | Metal |
Grate Details
| Grate Details | Cast Iron Grates , Continuous , Dishwasher Safe , Matte Finish |
| Number of Grates | 3 |
Dimensions
| Cutout Depth | 19-469/500Â in |
| Cutout Depth Max | 20 in |
| Cutout Height | 5-1/4 in |
| Cutout Depth Min | 19 in |
| Cutout Width | 34-1/2 in |
| Cutout Width Max | 35-1/4 in |
| Depth | 21 in |
| Gross Weight | 69-3/5 lbs |
| Height | 3-11/16 in |
| Net Weight | 61-3/5 lbs |
| Width | 36 in |
Controls
| Control Location | Front |
| Control Type | Knobs |
Ventilation Details
| Downdraft Vent | No |
Dimensions
| Gross Weight | 69-3/5 lbs |
Cooktop Details
| Cooktop Surface Color | Color Coordinated |
| Cooktop Surface Material | Stainless/Porcelain Coated Steel |
| Digital Display | No |
| Griddle Included | N/A |
| Heating Element On Indicator Light | No |
| Hot Surface Indicator Light | No |
| Ignition Type | Direct Spark Ignition |
| Combination Match with Oven | MEW9527 , MEW9530 |
| Installs Over Built-In Oven | Yes |
Electrical Requirements
| Power Cord Included | Yes |
| Amps | 15 |
Documents
WarrantyDownload (PDF 1.0MB)
Parts ListDownload (PDF 1006.0KB)
Quick Reference SheetDownload (PDF 625.0KB)
Installation InstructionsDownload (PDF 4.6MB)
Owner’s ManualDownload (PDF 951.0KB)
Dimension GuideDownload (PDF 2.8MB)
Installation Oven and Cooktop CombinationsDownload (PDF 616.0KB)
Instruction SheetDownload (PDF 94.0KB)
MiscDownload (PDF 5.3MB)
