Description
FEATURES
| WiFi Connect | Built-In |
| Filler trim kit | JXTR32B |
| Cooktop Burner Type | 4 Induction Elements |
| Melt Setting | Yes |
| Fuel Type | Electric |
| Element – Left Front | 7″ 2500W |
| Indicator Lights | 4 Hot Surface Red Setting Level Indicators Surface Element “ON” |
| Element – Right Front | 11″ 3700W |
| Control Location | Front Center |
| Cooktop Type | Induction |
| Cooktop Surface | |
| Cooktop Control Features | All-Off Control Boost (All Elements) Chef Connect Control Lock Capability Keep-Warm Setting Kitchen timer LED Light level adjustment Melt Setting Pan Presence Sensor Pan Size Sensor Sound adjustment Sync-Burners Capability |
| WiFi Enabled Features | Chef Connect with Hoods/OTRs Interfaces with SmartHQ App Works with HestanCue Pans Works with Precision Cooking Probe |
| Timer | Yes |
| Element – Left Rear | 7″ 2500W |
| Control Type | Electronic Glide Touch |
| Element – Right Rear | 6″ 1800W |
| Product Type | Cooktop |
APPEARANCE
| Color Appearance | Black |
| Frameless | Yes |
WEIGHTS & DIMENSIONS
| Cooktop Size | 30.00 |
| Overall Height | 3 1/4 |
| Cabinet Width | 30.00 |
| Approximate Shipping Weight | 40.00 |
| Cutout Dimensions (Width x Depth) (In.) | 28.00 |
| Overall Width | 29 3/4 |
| Net Weight | 34.00 |
| Overall Depth | 21 3/8 |
POWER / RATINGS
| Max. Connected Load (kW) at 240V | 7.7 |
| Circuit Breaker (Amps) at 208V | 40 |
| Amp Rating at 240V | 40 |
| Max. Current Draw (Amps) at 240V | 32.1 |
| Max. Connected Load (kW) at 208V | 6.9 |
| Amp Rating at 208V | 40 |
| Max. Current Draw (Amps) at 208V | 33.2 |
| Circuit Breaker (Amps) at 240V | 40 |
ACCESSORIES
| Optional Accessories | JXPROBE1 – Precision cooking probe |
WARRANTY
| Parts Warranty | Limited 6 months entire appliance |
| Labor Warranty | Limited 6 months entire appliance |
CERTIFICATIONS
| Claims & Certifications | ADA Compliant UL CUL California Prop 65 |
